Stringing Power Line 5 Groove Hydraulic Wire Tensioner Hydraulic Pump Tianjin Parker

Name: Stringing Power Line 5 Groove Hydraulic Wire Tensioner Hydraulic Pump Tianjin Parker
Brand: Boyu
Price: 1 USD

China Stringing Power Line 5 Groove Hydraulic Wire Tensioner Hydraulic Pump Tianjin Parker wholesale

Brand Name : Boyu

Model Number : TY1x30D-1800-2

Certification : ISO9001

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 100sets/month.

Delivery Time : 15~25 days

Packaging Details : Container

Type : Stringing Equipment Hydraulic Cable Tensioner For Power Line

Max continuous tension : 30kN

Max conductor diameter : 40mm

Total weight : 3200kg

Overall dimension (length*width*height) : 4500*2000*2500mm

Engine : Single cylinder diesel engine

Hydraulic pump : Tianjin Parker

Main motor : Tianjin Parker

Contact Now

Stringing Equipment Hydraulic Cable Tensioner For Power Line 5 Groove Number

Max continuous tension	30kN
Speed at max tension	2.5km/h
Max speed	5km/h
Pull at max speed	15kN
Max reverse pulling force	20kN
Bull-wheel diameter	1800mm
Max conductor diameter	40mm
Groove number	5
Total weight	3200kg
Overall dimension (lengthwidthheight)	450020002500mm
Engine	Single cylinder diesel engine
Hydraulic pump	Tianjin Parker
Main motor	Tianjin Parker
Speed reducer	German Rexroth / Italy Brevini
Hydraulic meter	German
Single cylinder diesel engine	18kw(25hp)
Electrical system	12V

Stringing Power Line 5 Groove Hydraulic Wire Tensioner Hydraulic Pump Tianjin Parker

Customer support

Customer is our first priority

Our contact person will do the best to deal with the problems our customers encountered, in order to ensure our customers' satisfaction and without any commitment from your side. An introduction course has been planned for all the customers that buy Boyu machines, we provide free technical support by means of phone or mail. Also our customers can download operation and maintenance videos from our website.

We will provide some easily damaged parts of the equipment to ensure the normal operation.

If any quality problems such as design, manufacture, function or procedure occur within the guarantee period, BOYU shall take full responsibility and bear all the economic losses incurred.

If any other quality problems occurs within the guarantee period, BOYU shall provide online video service after receive the buyer’s notice in 24 hrs.

If any big quality problems occurs out of the guarantee period, BOYU will also provide online video service after receive the buyer’s notice in 48 hrs.

BOYU will provide a lifetime favorable price to the buyer with the materials and spare parts used in system operation, equipment maintenance, and guarantee 7days courier door by door.

History

Founded in 1993, Yixing city power machinery factory

Established in 1994, Yixing city Boyu power machinery Co., LTD

In 2001 the company passed ISO9001 certification, and obtain the AAA certificate

In 2006 attains the Wuxi city contract trustworthiness enterprise, also achieved famous brand product in Wuxi city

In 2007 attains the high-tech enterprise of Jiangsu province, also achieved brand-name products in Jiangsu province

In 2009 reworded significant achievement in Wuxi city

In 2010 Boyu cooperated with Germany famous Caesar Company establishing the Boset brand

In 2010 achieved the national ministry of science and technology innovation in science and technology project.

To November, 2013, Boyu enterprise has already sell puller and tension equipment (excluding mobile ground grinding) nearly 5000 sets.

Our products are sold well in Australia, Egypt, England, Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico, Algeria, Turkey, Peru, Colombia, Brazil, Argentina etc.
